A frame crane is a kind of material handling lift with the capacity of 0.5t to over 300 tons. It is the most common type of gantry crane system used in a variety of industries. This equipment falls in two main configurations, single girder and double girder. For your industrial facilities, if you need a material handling equipment loading and unloading light to heavy goods, the gantry crane will be a reasonable choice, both in the crane’s performance and its costs. What’s more, in our factory, you can get a tailor-made crane with leading design technologies.
Types of A Frame Crane for Sale
We can provide you with different types of cranes perfectly meeting your industrial requirements, including single girder, double girder, truss gantry crane, cantilever gantry crane and mobile gantry crane. All these cranes can meet both indoor and outdoor applications. With this reliable and durable crane, your industrial working efficiency will be highly promoted.
Single girder A-frame gantry crane parameters:
- Load capacity: 3-20t
- Span: 8-35m
- Lifting height: 6-18m
- Lifting speed: 0.33-8m/min
- Trolley running speed: 20m/min
- Crane running speed: 20m/min
- Work duty: A3, A4
Double girder gantry crane parameters:
- Load capacity: 5-500t
- Span: 18-35m
- Lifting height: 6-18m
- Lifting speed: 1.5-11.5m/min
- Trolley running speed: 10-40.1m/min
- Crane running speed: 16-50m/min
- Work duty: A3-A7
In addition, the cranes include adjustable gantry cranes, aluminum gantry cranes, cantilever cranes and so on. These kinds of cranes, some of them are manufactured from aluminum materials, some are produced with adjustable features, some are better used for indoor applications, however, some are widely applied in outdoor uses. The following is some of hot sale crane specifications for your reference.
Gantry crane specifications
The adjustable gantry crane is a kind of flexible crane used for both light and heavy loads applications. The mobile gantry cranes usually are outdoor cranes, widely applied for ports, railroads transports, ships or barges. If you are employed in these industrial fields, it will be better for you to buy a mobile gantry crane from us to promote your business productivity.
Cantilever crane is a heavy duty crane used for outdoor heavier material applications. If your factory needs an crane to do heavy loads applications, the cantilever one will be a top choice for you.
The gantry cranes are smart lifts for your home appliances use. The prime feature of this kind of crane is easy to operate and best customized for your homemade application requirements.
The crane is a kind of light duty crane for interior material handling applications. This light duty crane is capable of handling lighter loads with the capacity of 1t to 20t. If your working applications need a light duty crane for your light loads material handling applications, the overhead a frame lifts will be your ideal choice.
How Much Does A Frame Crane Cost?
The above mentioned types of cranes are best sales in our company. And their prices are also at different levels since loads and configurations difference. However, all types of cranes are all at factory price level, since all of them are directly sold from our own factory. Usually, the overhead cranes’ prices and the a-frame cranes prices are will cost you less than the gantry cranes, and the cantilever cranes. Since the former two are light duty cranes and the latter two are heavier loads ones, their prices are lower than the heavier loads ones. Thus, before you buy a crane for your industry, that will be better to make a budget to the types of cranes you need. If you have to know idea the right crane for your industry, come in connection with us, our professional crane expert teams will tailor you crane purchasing plans for your industry which will be strictly in alliance with your crane purchasing budgets and meeting your industrial working applications.
A-frame Crane Design
The crane design is strictly in accordance with the crane manufacturing standards both at home and abroad in materials and structures. In the capacity design, the cranes have a design factory of 15% the allowable capacity for the weight of the hoist and 25% for impact. All types of A frame cranes are anti-swing featured meeting the latest research crane manufacturing standards.
