Aicrane gantry crane in the Philippines is committed to providing customers with versatile and customizable solutions that can be designed and built to meet specific lifting and material handling needs. After years of hard work, Aicrane has set up an overseas office in the Philippines, which can provide local customers with one-stop services including gantry crane design, manufacturing, delivery and installation, and after-sales service.
Common Gantry Crane Solutions in the Philippines
Aicrane gantry crane for sale in the Philippines can be custom designed and built to meet your specific lifting and material handling needs. Here are some common gantry crane solutions from Aicrane: single girder gantry cranes, double girder gantry cranes, semi gantry cranes, rubber tired gantry cranes, rail mounted gantry cranes, etc.
Single-girder gantry crane
This type of crane is designed with a single horizontal beam that supports the hoist and trolley. It is typically used for lighter loads and is ideal for applications that require a low headroom or a tight workspace. Our single girder gantry crane for sale in the Philippines can be standard configuration or European standard configuration to meet the specific lifting and material handling requirements of the application.
| Model | AQ-MH |
|---|---|
| Load capacity | 3-20t |
| Span | 8-35m |
| Lifting height | 6-18m |
| Lifting speed | 0.33-8m/min |
| Hoist running speed | 20m/min |
| Crane running speed | 20m/min |
| Work duty | A3, A4 |
| Custom designs available | |
| Model | AQ-NMH |
|---|---|
| Load capacity | 3.2-20t |
| Span | 8-35m |
| Lifting height | 6-12m |
| Lifting speed | 0.66-5m/min |
| Hoist running speed | 2-20m/min |
| Crane running speed | 3-30m/min |
| Work duty | A5 |
| Custom designs available | |
Double-girder gantry crane
This type of gantry crane has two horizontal beams that support the hoist and trolley. It is used for heavier loads and can provide a higher lifting capacity compared to single-girder gantry cranes. There are various types of double girder gantry cranes available at Aicrane: European standard, A frame and U frame designs.
| Model | AQ-MG |
|---|---|
| Load capacity | 5-500t |
| Span | 18-35m |
| Lifting height | 6-18m |
| Lifting speed | 1.5-11.5m/min |
| Trolley running speed | 10-40.1m/min |
| Crane running speed | 16-50m/min |
| Work duty | A3-A7 |
| Custom designs available | |
Semi-gantry crane
This type of crane is designed to operate on one leg, while the other end is supported by a building column or wall. It is ideal for applications where there is limited space or when the crane needs to be positioned near a wall or obstacle.
Rubber-tired gantry crane
This type of mobile gantry crane is designed to move on rubber tires and is used for various industrial applications such as concrete precast, external logistics warehousing, wind energy, tunnel construction, power plants and more.There are various types of rubber tyred gantry cranes for sale in the Philippines: electric drive, hydraulic drive, single beam and double beam designs.
| Model | RTG |
|---|---|
| Load capacity | 5-500t |
| Span | 5-35m |
| Lifting height | 6-18m |
| Lifting speed | 1-10m/min |
| Trolley running speed | 2-20m/min |
| Crane running speed | 3-30m/min |
| Work duty | A3-A5 |
| Custom designs available | |
Rail mounted gantry crane
This type of crane is commonly used in container yards, railway, and ports to load and unload containers. These RMG cranes are designed to work in all weather conditions and are equipped with various safety features, such as anti-collision devices and wind speed sensors, to ensure safe and efficient operation. They are also designed to be energy-efficient and environmentally friendly, with features such as regenerative braking and variable frequency drives.
| Model | RMG |
|---|---|
| Load capacity | 30-50t |
| Span | 18-35m |
| Lifting height | 12.3-21m |
| Lifting speed | 9.2-12.5m/min |
| Trolley running speed | 45-56m/min |
| Crane running speed | 42-50m/min |
| Work duty | A6-A8 |
| Custom designs available | |
Industries Using Gantry Cranes in the Philippines
Gantry cranes in the Philippines are designed to lift and move heavy loads and equipment in a precise and efficient manner. They are commonly used in the Philippines for various industries such as shipping and logistics, manufacturing, energy, construction and more. What we do is to provide the right gantry crane solutions for various industries in the Philippines!
Construction
Gantry cranes are commonly used in construction sites to lift and move heavy building materials, such as steel beams, concrete blocks, and precast concrete panels. Our gantry crane solution for this industry is to use single girder gantry cranes, double girder gantry cranes, rubber tyred gantry cranes, etc.
Manufacturing
Gantry cranes are used in manufacturing plants to move heavy machinery, equipment, and products, such as metal structures, automobiles, airplane parts, and large appliances. Our gantry crane solutions for this industry are using single girder gantry cranes, double girder gantry cranes, semi gantry cranes, rubber tire gantry cranes, etc.
Energy
Gantry cranes are used in power plants and utility sites to move heavy equipment, such as turbines and generators. In power plants, double girder gantry cranes are often used for heavy lifting tasks, while single girder gantry cranes may be used for lighter tasks. Rubber tired gantry cranes are a more flexible solution for lifting and moving heavy equipment.
Shipping and logistics
The major ports in the Philippines such as the Port of Manila, which is the largest and busiest port in the country, the Port of Cebu and the Port of Batangas, have gantry cranes that are used for container and cargo handling. We provide custom rail mounted gantry crane solutions for ports and logistics stations to load, unload and handle containers.
Overall, gantry cranes play a crucial role in the economy of the Philippines by facilitating the movement of goods and materials within the country and between the Philippines and other countries. Contact us now to get a suitable gantry crane solution for your industry in the Philippines!
Steps to Obtain a Suitable Gantry Crane Solution
To get a suitable gantry crane solution in the Philippines, you can follow these steps:
- Determine your lifting and material handling requirements: Consider the weight and size of the loads you need to lift and move, the frequency of the lifts, the distance the loads need to be moved, and any special handling requirements. This information will help you determine the appropriate gantry crane solution for the job.
- Determine your budget: Work with the gantry crane suppliers in the Philippines, and they will provide expert advice and guidance on the type and size of gantry crane that will best fit your budget.
- Contact a reputable gantry crane manufacturer or supplier in the Philippines: Research and reach out to manufacturers or suppliers of gantry cranes in the Philippines who can provide customized solutions to meet your specific requirements. Look for a company that has experience in designing and building gantry cranes for similar applications.
- Review the gantry crane proposal: The gantry crane supplier will present a proposal that outlines the specifications of the gantry crane, the delivery and installation timeline, and the price of the equipment. Review the proposal carefully and ask any questions or concerns you may have before proceeding.
It’s important to work with a reputable and experienced gantry crane supplier in the Philippines to ensure that you get a safe and reliable solution that meets your lifting and material handling needs. If you are interested in getting a suitable gantry crane solution for your business, simply contact Aicrane!
Aicrane Services in the Philippines
- Customized gantry crane solution design: Aicrane’s professional crane engineers and project consultants will fully discuss product requirements and budget with customers, and provide customized solutions for specific applications of customers.
- Order one-on-one follow-up: We have a customer service team to follow up each customer’s order execution one-on-one, regularly update the production progress to customers, arrange delivery, installation and other work in advance, to ensure that the equipment is completed on time and delivered to the customer site smoothly.
- Installation service: According to customer requirements, Aicrane installation engineers can be arranged to guide the installation online or on site to ensure the normal operation of the equipment. We also offer operator training services including operation, maintenance, troubleshooting and more.
- After-sales service: Our after-sales service specialist will visit customers regularly to check the operation of the equipment and remind customers to maintain the equipment. Our after-sales service is available 24/7.
